Name: Heavy Duty 6x4 Diesel Cargo Truck 40T Load Capacity ABS Brake System
Brand: Shandong Global Heavy Truck Import&Export Co.,Ltd
SKU: howo
Price: negotiable USD
Availability: InStock

Home Products Mining Dump Truck

Heavy Duty 6x4 Diesel Cargo Truck 40T Load Capacity ABS Brake System

Product Details:

Place of Origin:	China
Brand Name:	sinotruk
Certification:	iso/ccc
Model Number:	howo

Payment & Shipping Terms:

Minimum Order Quantity:	1 PCS
Price:	Negotiable
Packaging Details:	Nude
Delivery Time:	30-45 work days
Payment Terms:	L/C, T/T
Supply Ability:	500 units/month

Contact Now

Detailed Product Description

Model NO.:	ZZ3257N4347W	Transmission Type:	Manual
Power:	Diesel	Load Capacity:	41-50t
Emission Standard:	Euro 2	Drive Wheel:	6×4
Engine Capacity:	＞8L	Engine Make:	WEICHAI
Loading Capacity:	25 Cubic Meters	Fuel Tank Capacity:	500L
Cab:	HOWO7D, With Air Conditioner	Tires:	59/80R63
Specification:	6.92.553.25m	HS Code:	8704223000
Origin:	Shandong, China

Heavy Duty 6x4 Diesel Cargo Truck 40T Load Capacity ABS Brake System

The ZZ3257N3847A HOWO tipper truck integrates cutting-edge technologies from the truck industry, making it ideal for transporting various materials like sand, rocks, soil, waste, construction supplies, coal, minerals, grain, and agricultural products. Its standout feature is the mechanized unloading system, which boosts efficiency and lessens manual labor. Widely used in sectors such as transportation and construction, this truck is powered by a WD615 series engine with horsepower ranging from 336HP to 371HP. It has a cargo box measuring 5.6 meters in length and 2.3 meters in width. The truck can reach a top speed of 75 km/h and is equipped with an HW19710 gearbox.

ZZ3257N3847A
Body	Carriage Internal Dimensions(mm)			5600x2300x1500
	Cubage (m3)			19.3
	Steel thickness of Carriage(mm)			Floor:8mm/Side:6mm
	Steel			Q235
	Hydraulic Lift of Carriage			Middle Lift
Weight in kg	Kerb weight (Kg)			12270
	Gross vehicle weight (Kg)			30000
Dimension(mm)	Dimensions(mm)	Length(mm)		8245
		Width(mm)		2550
		Height(mm)		3450
	Wheel base (mm)			3800+1350
Performance	Maximum driving speed (km/h)			75
	Fuel consumption (1/100 km)			38
Cab	Model		SINOTRUK HW76 cab Single bunk,new type seat,adjustable steering wheel,EURO new type heating & ventilating system,German VDO instruments,safety belts, exterior sun visor,stereo radio/cassette recorder,left driving,air conditioner
Engine	Model		WD615.47(Euro 2)
	Type		6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection
	Horsepower		371
	Maximum output Kw/r/min		273/2200
	Maximum torque N.m/r/min		1460/1300-1600

	Valve		2
	Displacement		9.726L
	Make SINOTRUCK (CNHTC), Euro II emission standard, Thermostat with 80ºC opening begin, Rigid fan
Transmission	SINOTRUK HW19710 transmission ,10 forward and 2 reverse
Clutch	SINOTRUK Φ430 diaphragm-spring clutch,hydraulically operating with air assistance
Steering	ZF8118 Steering Gear Box ,hydraulic steering with power assistance.(Left hand driving)
Front Axle	SINOTRUK HF9 Front Axle,new 9-ton front axles of equipped with drum brakes.
Rear Axles	SINOTRUK HC16 Heavy reduction drive axle,STR hub-reduction with differential locks between wheels and axles, enforced STR axle,ratio:5.73;The basic configuration of HOWO series construction vehicle can be used in such bad environment as bad road condition, heavy impact and overloading, which is the best choice for heavy construction vehicle customers.
Brake System	Service brake:dual circuit compressed air brake Parking brake (emergency brake):spring energy,compressed air operating on rear wheels
Wheels & Tyres	Rims:10 hole-steel ;Tyres:13R22.5 tubeless tyre with one spare tyre

Oil Tank	Square type-300L Aluminum alloy fuel tank
