HOWO Truck 6X4 Dump Truck Sinotruk Tipper 10 Wheel 50 Tons Tractor Truck
A tractor unit, also known as a truck head or trailer head, is a robust towing engine designed to provide the driving force for pulling trailers or towed loads. This combination of tractor and trailer allows for efficient load distribution across multiple axles, offering greater maneuverability compared to a similarly sized rigid truck. The most common method of attaching a trailer is via a fifth wheel coupling, which enables quick switching between trailers for various functions, such as swapping between a bulk tipper and a box trailer. This system allows for rapid interchange of trailers carrying different cargoes, minimizing downtime during loading or unloading processes.
We are committed to providing excellent service and therefore offer a one-year warranty period. In the event of quality issues with accessories under normal usage conditions, we will supply free replacements. The accessories covered include axles, saddles, leaf springs, kingpins, landing gears, suspensions, tires, and air chambers. Furthermore, we ensure that solutions to any quality problems are provided within half an hour. Our quality control team will promptly respond to customer inquiries and guide them through resolving any issues. All our engineers are highly experienced in tractor head trucks, and we are dedicated to offering the best solutions and extensive maintenance knowledge.
The Howo A7 tractor heads are manufactured by Sinotruk Group, the largest truck exporting manufacturer, and enjoy a strong reputation for their reliable performance, cost-effectiveness, and loading capacity. We present the Howo A7 tractor heads to our clients, promoting them both domestically and internationally. To cater to diverse needs, we offer 6x4 and 8x4 drive configurations, as well as options for left-hand drive or right-hand drive, allowing clients to choose based on their country's traffic regulations.
The rated power and kW/rpm range from 249/1900 to 309/2000. Our dump trucks come with a choice of AMT or MT transmissions, including models such as HW13710, HW15710, HW 19710(A), HW19710T, HW-9712, and HW20716, enabling clients to select according to their specific requirements. Additionally, overdrive gears and aluminum casings are available as options, and ZF transmissions can be selected. We offer five types of cabins: A7-P, A7-G, A7-W, A7-V, and A7-B. Clients can choose between long or standard cabs, as well as low or high floor options. The low floor A7 Howo cabin features one bunk, while the high floor version has two bunks. To suit markets in Africa, Southeast Asia, Central Asia, and beyond, we utilize trucks with a Euro 3 emission standard, resulting in relatively lower maintenance costs for our clients.
FAQ:
-
What are your payment terms? We primarily accept T/T (30% advance payment with the balance due before shipping) and L/C. However, please feel free to contact us if you prefer alternative payment arrangements.
-
What is the delivery time? For the HOWO 371 truck head, we will arrange shipment within 40 days after receiving the advance payment.
-
How long is the warranty period? We provide a one-year warranty for the truck.
-
How do you support after-sales service? We offer lifelong after-sales support. Our engineers are available for overseas training, and spare parts will be dispatched as quickly as possible.
| Truck Brand |
SINOTRUK—STW |
| Dimension(Lx W xH)(unloaded)(mm) |
6800*2496*3668 |
| Approaching angle/Departure angle(°) |
16/70 |
| Overhang(front/rear) (mm) |
1500/725 |
| Wheel base (mm) |
3200+1400 |
| Max speed(km/h) |
102 |
| Curb weight(kg) |
9210 |
| Loading Weight(kg) |
39200 |
|
Engine
(Steyr technology, made in China)
|
Model |
WD615.96E,4 stroke direct injection diesel engine, 6-Cylinder in-line with water cooling, turbo-charger and inter-cooling |
| Engine Type |
common rail electronic computer controlled |
| Fuel type |
Diesel |
| Horse Power, max(kw/rpm) |
371hp
|
| Emission |
EURO II |
| Fuel tanker capacity (L) |
400L |
| Brake system |
Service brake |
Dual circuit compressed air brake |
| Parking brake |
spring energy, compressed air operating on rear wheel |
| Auxiliary brake |
Engine exhaust brake |
| Steering system |
Model |
ZF8098 hydraulic steering with power assistance |
| Front axle |
HF7 with disc brake |
| Rear axle |
HW16 double driving axle, the HOWO driving axle is one of the biggest single reducer axles among the world, strong enough to bear big loading capacity, easy to get maintenance, Ratio: 4.22(ST16,HC16,AC16) |
| Color |
Optional |
| Tire |
295/80R22.5 tubeless tire |
| Tire Quantity |
10+1 spare |
| Fifth wheel |
50mm |
| Electrical system |
Battery |
2X12V/165Ah |
| Alternator |
28V-1500kw |
| Starter |
7.5Kw/24V |
Our Services:
Pre-Sales Service: A professional sales team provides personalized services based on customer requirements.
Order Processing: We initiate production of your order within 3 days, ensuring strict quality control throughout the process.
Shipping Arrangements: Our logistics department handles shipping according to your specific requirements. We will deliver the Sinotruk HOWO 371 truck head to you with professional service. All necessary customs clearance documents, including contracts, commercial invoices, packing lists, and certificates of origin, will be provided.
After-Sales Support:
-
Regular follow-ups to monitor the performance of the tipper truck and provide technical recommendations.
-
Prompt supply of spare parts to ensure continuous operation of the HOWO 371 truck head.
-
Our overseas engineers are always on standby to provide assistance.
FAQ:
1. What are your payment terms? We primarily accept T/T (30% advance payment with the balance due before shipping) and L/C. However, feel free to contact us if you prefer alternative payment arrangements.
2. What is the delivery time? The HOWO 371 truck head will be shipped within 40 days after receipt of the deposit.
3. How long is the warranty period? We offer a one-year warranty on the truck.
4. How do you provide after-sales service? We provide lifelong after-sales support. Our engineers are available for overseas training, and spare parts will be dispatched as quickly as possible.
